Feature
Low Insertion
Loss High Isolation
Low polarization sensitivity
Excellent environmental reliability
Applications
EDFA
Fiberlaser
Research

Specifications

Fiber Type					SMF-28
Grade					P
Operating Wavelength (nm)					1480/1550
Operating Band					1480/1550±5nm
Insertion Loss (dB) Max.					0.3
Isolation (dB)					≥15(test center wavelength≥20）
Polarization Dependent Loss (dB)					≤ 0.10
Directivity (dB) Min.					50
Insertion Loss Delta from: 0 C - 55 C (dB)*					≤ 0.15
Operating Temperature					-20 C - 70 C
Storage Temperature					-40 C - 85 C
Fiber Pigtail Length (m)					≥1
Port Configuration					1x2
Package Dimension (mm)					3*54
Connector					--

I/L not include connector loss. ( 0.2dB/connector)

Ordering Information

WDM	Type	Wavelength	Pigtail Type			Fiber Type		Fiber Length		Connector
	1x2	1480/1560nm	250=250um bare fiber			1=HI1060 Flex		0.8=0.8m		NE=None
			900=900um loosetube			2=SMF28		1=1m		FA=FC/APC
			3000=3mm loose tube					2=2m		FC=FC/UPC
								X=Other		SA=SC/APC
										SC=SC/UPC
										LA=LC/APC
										LC=LC/UPC
										XX=Other
