Applications
Long-haul backbone network transmission
Metropolitan area networks and regional networks
Data center optical interconnection
Features
High gain and wide bandwidth characteristics
High power output and linear amplification capability
Low noise and high reliability

Specifications

Parameter	unit		min		max
Wavelength Range	nm		1525		1565
Input Power	dBm		-10		0
Output Power	dBm		0		23
Operating Temperature	℃		15		55
Storage Temperature	℃		-5		55
Operating Voltage	dBm		12V/3A
Adapter and Ferrule Options	V/A		Assemble according to customer requirements
Insertion Loss	dBm		0.1		0.2
Product Dimensions	CM		Length:15cm width:9cm Height:2.6cm
Communication Mode	CM		232TTL转USB
Note: The data in the table are all reference values, and the actual situation depends on user requirements.
