Applications
Long-haul backbone network transmission
Metropolitan area networks and regional networks
Data center optical interconnection
Features
High gain and wide bandwidth characteristics
High power output and linear amplification capability
Low noise and high reliability

Specifications

Parameter						unit		min			max
Wavelength Range						nm		1525			1565
Input Power						dBm		-10			0
Output Power						dBm		0			23
Operating Temperature						℃		15			55
Storage Temperature						℃		-5			55
Operating Voltage						dBm		5V/3A
Adapter and Ferrule Options						V/A		Assemble according to customer requirements
Insertion Loss						dBm		0.1			0.2
Product Dimensions						CM		Length:9cm width:7cm Height:1.4cm
Communication Mode						CM		232TTL 转 USB
Note: The data in the table are all reference values, and the actual situation depends on user requirements.
