Applications
Optical communication field
Optical network testing and debugging
Optical fiber sensing field
Features
Intelligence
Multi-channel adjustment
Stability and reliability

Specifications

Parameter		unit		Value
Switching Error		dBm		≤-0.03
Operating Temperature		℃		-20～+80
Response Time		ms		≤8
Attenuation Range		nm		≤30
Return Loss		dBm		SM≥50，MM≥30
Insertion Loss		dBm		1.2～1.8
Wavelength Range		nm		1260~1620
Communication Interface				Micro_USB
Operating Voltage		V/A		12V/3A
Product Dimensions		CM		Length：17.24cm   Width：10.2cm  Height：3cm
Number of Channels				8ch（8IN,8OUT）
Adapter and Ferrule Options				Assemble according to customer requirements
Note: The data in the table are all reference values, and the actual situation depends on user requirements.
