| LW-LS Series Hand-held Optical Light Source features in high output power, narrow optical spectrum, high side-mode suppression ratio etc. It is an essential instrument for field or laboratory testing of optical communication which can be used with an optical power meter for measuring optical loss on single-mode or multi-mode fiber cable. It features compact size, high output power, stable output power and excellent wavelength stability. Lightwit Photonics company takes “Quality and Credit come first” as its base of exist and development. ISO9001 and CE assure the qualities for our customers,. Firmly through quality product line, effective research, manufacture and market management and with nearly a decade accumulation on industry insight and expertise, we have forged strong ties to customers from all over the world.
Key Features:
◆Large Color LCD display
◆Easy operation with one key to change wavelength
◆Battery low voltage detecting and displaying
◆High stability of output power
◆Output power mode CW or modulation mode can be optional
◆Unique FS/SC/ST universal adapter
◆Provides dual-wavelengths output and wavelengths can be optional according to customers needs.
Applications:
◆Maintenance in Telecom
◆Maintenance CATV
◆Fiber Optic Lab Testing
◆Other Fiber Optic Measurements
Technical Parameters:
|
Style:
|
LW802-LDS/A
|
LW802-LDS/B
|
LW802-LDS/.C
|
|
Emitter Type:
|
LD
|
|
Operation wavelength(nm):
|
850 ±30
|
1310 ±30
|
1550 ±30
|
|
Spectral Width(nm):
|
≤5nm
|
|
Degree of stability
(short dated)(dB/5min):
|
±0.06
|
±0.03
|
±0.03
|
|
Degree of stability
(extended)(dB/6hours):
|
±0.2
|
±0.1
|
±0.1
|
|
Output power
(dBm 9/125 SMF):
|
≥0
|
|
Output Style:
|
FC/SC/ST
|
|
Operation environment:
|
-15+55; ≤95% no coagulation
|
|
Storage environment:
|
-35+70; ≤95% no coagulation
|
|
Battery Operating Time:
|
2AA(5’’)>48h
|
|
Dimension(mm):
|
62*125*23*
|
|
Weight(g):
|
100g
|
|
|
Accessories in the package:
|
User Manual
|
|
Qualified Certification
|
Power Adapter
|
Specification
|
|
1 copy
|
|
1 copy
|
1
|
1 copy
|
Ordering Information:
LW-LS-A
LW-LS-B
LW-LS-C
|
