Fiber Optic Attenuators

  Product Description:

Attenuator as a fiber optical passive devices for optical communication systems performance optical power debug, debug Fiber Instrument calibration correction, the fiber-optic signal attenuation. Use products containing the metal ions made of fiber attenuation, the optical power can adjust to the required level. Lightwit Phoconics Co., Ltd takes “Quality and Credit come first” as its base of exist and development. ISO9001 and CE assure the qualities for our customers. Firmly through quality product line, effective research, manufacture and market management and with nearly a decade accumulation on industry insight and expertise, we have forged strong ties to customers from all over the word.


Key Features:

Attenuates continuously and precisely
Environmentally Stable and Reliable
Wide Operating frequency band
Low PDL
Low return loss
Simple manipulation
High power endurance


Application:

ODF Transmission System
Connecting optical communications equipment
Telecom Network
LAN
Cable
High-speed, high-capacity SDH Optical Fiber Transmission

Environmental requirements:

Ambient temperature:-20~+70
Storage temperature: -40~+70

High Return Loss type(type sockets)Specifications:
Type
Attenuation
Values(dB)
Precision error
(dB)
Wavelength
Additional Loss
(dB)
Connector type
(dB)
High Return
Loss
1-30dB
1~5dB<±0.1dB
1310nm
Insertion Loss
FC/UPC
1550nm
≤0.2dB(UPC)
FC/APC
1310nm/1550nm
≤0.3dB(APC)
SC/UPC,SC/APC


Return Loss

5~10dB<±0.3dB

≥50dB(UPC)
LC/UPC,LC/APC
10~20dB<±0.5dB

≥65dB(APC)
ST/UPC,MU/PC
High Return Loss type(type sockets)Environmental:

Pilot projects:
Test conditions
Temperature and
Humidity aging:
Temperature is 85 . relative humidity is85%, Insertion loss≤0.1dB in 14 days
Temperature cycle:
Temperature is -40~+70℃,relative humidity is 10%~80%, 42 cycles, Insertion loss≤0.1dB in 14 days
Soaking:
Temperature is 43℃, PH5.5, Insertion loss≤0.1dB in 7 days
Vibration:
Amplitude is 1.52mm, frequency is 10Hz~55Hz, three directions of the two hour insertion loss≤0.1dB
Bending load:
0.454kg load 100 cycles(Jacketed) insertion loss≤0.1dB
Load reverse:
0.454kg load 10 cycle(Jacketed) insertion loss≤0.1dB
Anti-Tension:
0.23kg Rally(bare fiber), 1.0kg(jacketed) insertion loss≤0.1dB
Impact:
1.5m high, three direction, 8 time/direction, Insertion loss≤0.1dB
Reference
Standards:
Bellcore TA-NWT-001209 Insertion loss≤0.1dB

Adjustable-technical parameters;’
Is composed of three sections of metal nut, includes two activity FC connector, through the adjustment: two locked FC joint activities to generate the required distance from the attenuation
Type
Regulation:
Attenuation
Accuracy(dB)
Wavelength
(nm)
Return Loss:
(dB)
Adjustable
0~30dB
±10%dB
1310nm/1550nm
>20dB

Adjustable-environment tests:
Continuous crash(4000) is less than 0.2dB insertion changes in reflectivity greater than 35dB
Drop Test: Change is less than 0.2dB insertion reflection greater than 35dB
Bending test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Distorted test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Stubbs poor durability test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Tensile test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Adapter joint resistance: 200-400gf 200-400gf
Vibration test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Salt spray test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Thermal shock test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Operating Temperature: -20-+70
Storage temperature: -40-+70

Flange-fbier attenuation

Use flange way to achieve this, the connector can be used multiple methods. For example: FC.SC.ST easy installation, simple structure

Type
Attenuation
Values(dB)
Precision error(dB)
Wavelength
Return Loss
(dB)
Connector
Type
(dB)
Flange-fiber
Attenuation
1-2
≤±0.25dB
1310nm/1550nm
≥35dB
FC;SC/PC
3-15
≤±10%dB
1310nm/1550nm
≥35dB
FC;SC/APC
15-30
≤±1.5dB
1310nm/1550nm
≥35dB

Fiber-optical attenuator flange Reliability Test condition:
Continuous crash(4000) is less than 0.2dB insertion changes in reflectivity greater than 35dB
Drop Test: Change is less than 0.2dB insertion reflection greater than 35dB
Bending test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Distorted test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Stubbs poor durability test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Tensile test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Adapter joint resistance: 200-400gf 200-400gf
Vibration test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Salt spray test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Thermal shock test: insert changes in reflectivity is less than 0.2dB greater than 35dB
Operating Temperature: -20-+70
Storage temperature: -40-+70

Online technology indicators:
Type
Attenuation
Values(dB)
Precision error(dB)
Wavelength
Return Loss(dB)
Connector type
Online-
flange
1-30dB
1~5dB<±0.1dB
1310nm
Insertion Loss
FC/UPC
1550nm
≤0.2dB
(UPC)
FC/APC
1310nm/1550nm
≤0.3dB
(APC)
SC/UPC,
SC/APC
5~10dB<±0.3dB

Return Loss
LC/UPC,
LC/APC
10~20dB<±0.5dB

≥50dB
(UPC)
ST/UPC,
ST/APC


≥65dB
(APC)


Online-Reliability Test conditions:
Pilot projects:
Test conditions
Temperature and
Humidity aging:
Temperature is 85 . relative humidity is85%, Insertion loss≤0.1dB in 14 days
Temperature cycle:
Temperature is -40~+70℃,relative humidity is 10%~80%, 42 cycles, Insertion loss≤0.1dB in 14 days
Soaking
Temperature is 43℃, PH5.5, Insertion loss≤0.1dB in 7 days
Vibration:
Amplitude is 1.52mm, frequency is 10Hz~55Hz, three directions of the two hour insertion loss≤0.1dB
Bending load:
0.454kg load 100 cycles(Jacketed) insertion loss≤0.1dB
Load reverse:
0.454kg load 10 cycle(Jacketed) insertion loss≤0.1dB
Anti-Tension:
0.23kg Rally(bare fiber), 1.0kg(jacketed) insertion loss≤0.1dB
Impact:
1.5m high, three direction, 8 time/direction, Insertion loss≤0.1dB
Reference
Standards:
Bellcore TA-NWT-001209 Insertion loss≤0.1dB

Ordering information:

No.
Description
LW-VOA
Variable Type
LW-VOA-L
Variable Type, Lan Type
LW-FOA-FF
Fixed Attenuator, Female to Female
LW-FOA-MF
Fixed Attenuator, Male to Female
LW-VOA-MF
Variable Type, Male to Female
LW-FOA-L
Variable Type, In-Line Type
For drawings, technical data or samples configuration other than stated above, please feel free to contact us:  sales@lightwit.com.cn
